Ball valve with red butterfly handle Nile 1/2" M x 1/2" F 763603
€ 8,00
(Incl. 21%)
€ 6,61
(Excl. 21%)
The ARCO 763603 from the Nile range is a ball valve with a red butterfly handle.
This version has a 1/2" M x 1/2" F connection, a maximum working pressure of PN 25 bar and a temperature range of -20 to 100 °C. The body is made of Brass CW617N, nickel plated.
Features
- European Brass, DW quality for use in drinking water installations.
- 100% leak tested.
- Strong construction and safe installation.
- Double o-ring ensures external tightness.
- Lever handle with epoxy protection.
- Stainless-steel nuts for all handles (lever, butterfly and square)
Application
Quarter-turn ball valves with manual operation, connected to the pipe by threaded ends.
Loyalty Points
Earn from this purchase
+3
points
Max discount with points
4.00€
Using 400 points
Purchase this item to earn 3 points. As a loyalty member, you can use your points to save up to 4.00€ on this order!
Returns
14-day return policy
Secure Payment
Guarantee secure payments
24/7 Dedicated Support
Anywhere & anytime
Hotline Order:
Mon - Fri: 08:00 / 16:00
+31 854885920
| Product code | 763603 |
| Brand | ARCO |
| Series | Nile |
| Connection | 1/2" M x 1/2" F (supplier notation: 1/2M-1/2F) |
| Max. pressure | PN 25 bar |
| Temperature | -20 to 100 °C |
| Material body | Brass CW617N, nickel plated |
| Dimension A | 53 mm |
| Dimension B | 56 mm |
| Dimension C | 38 mm |
| Packaging | Supplier packaging: inner box 25 pcs, outer box 50 pcs |
| Technical sheet | Download PDF |
| Certificate | Certificate of sanitary conformity (ACS) 23 ACC NY 004 |
| EAN code | 8428519086063 |
