Ball valve with square 20x20 mm handle Nile 1" F x 1" F 765105
€ 15,71
(Incl. 21%)
€ 12,98
(Excl. 21%)
The ARCO 765105 from the Nile range is a ball valve with a square 20x20 mm handle.
This version has a 1" F x 1" F connection, a maximum working pressure of PN 25 bar and a temperature range of -20 to 100 °C. The body is made of Brass CW617N, nickel plated.
Features
- European Brass, DW quality for use in drinking water installations.
- 100% leak tested.
- Strong construction and safe installation.
- Double o-ring ensures external tightness.
- Lever handle with epoxy protection.
- Stainless-steel nuts for all handles (lever, butterfly and square)
Application
Quarter-turn ball valves with manual operation, connected to the pipe by threaded ends.
Loyalty Points
Earn from this purchase
+7
points
Max discount with points
7.85€
Using 786 points
Purchase this item to earn 7 points. As a loyalty member, you can use your points to save up to 7.85€ on this order!
Returns
14-day return policy
Secure Payment
Guarantee secure payments
24/7 Dedicated Support
Anywhere & anytime
Hotline Order:
Mon - Fri: 08:00 / 16:00
+31 854885920
| Product code | 765105 |
| Brand | ARCO |
| Series | Nile |
| Connection | 1" F x 1" F (supplier notation: 1F-1F) |
| Max. pressure | PN 25 bar |
| Temperature | -20 to 100 °C |
| Material body | Brass CW617N, nickel plated |
| Dimension A | 59 mm |
| Dimension B | 20 mm |
| Dimension C | 50 mm |
| Packaging | Supplier packaging: inner box 10 pcs, outer box 20 pcs |
| Technical sheet | Download PDF |
| Certificate | Certificate of sanitary conformity (ACS) 23 ACC NY 004 |
| EAN code | 8428519086230 |
