BONFIX brass compression fitting end cap 15 - 40052745
- End coupling for shutting off a pipe.
- Brass robust and durable design.
- 15 mm suitable for 15 mm copper tube.
- Assembly: no soldering or crimping tools required.
- Approved, KIWA and GASTEC QA compliant.
Loyalty Points
Earn from this purchase
Max discount with points
Hotline Order:
Mon - Fri: 08:00 / 16:00
+31 854885920
Key features
- End coupling for shutting off a pipe.
- Brass robust and durable design.
- 15 mm suitable for 15 mm copper tube.
- Assembly: no soldering or crimping tools required.
- Approved, KIWA and GASTEC QA compliant.
Product information
The BONFIX brass compression fitting end coupling 15 mm is designed for safely and neatly closing off a copper pipe. This end coupling is widely used for temporary closures, modifications to existing installations, or as a permanent end stop. Thanks to the compression connection, you can install the coupling quickly and reliably without soldering or pressing. After tightening, a solid and leak-free seal is created.
Why BONFIX?
BONFIX compression fittings have been developed with a focus on practical use and a strong price-quality ratio. The flattened wrench surface provides extra grip during assembly, while the slightly conical locating surface in the union nut ensures that the pipe is smoothly accommodated. The end coupling is designed according to EN 1254 2 and meets European UBA requirements. With KIWA and GASTEC QA certification, you can be sure that this coupling is suitable for professional use.
Features
| Property | Value |
|---|---|
| Article number | 40052745 |
| GTIN number | 8717845213107 |
| Brand | BONFIX |
| Type | End coupling |
| Manufacturer's article number | 82495 |
| Mate | 15 |
| Model | End cap |
| Application | Gas / Drinking water / CV |
| Connection 1 | Terminal connection |
| Connection quality class 1 | CuZn40Pb2 (CW617N) |
| Material connection 1 | Brass |
| Material sealing | Brass |
| Max. operating pressure at max. medium temperature | 16 bar |
| Max. working pressure at 20°C | 16 bar |
| Medium temperature (continuous) | -20 - 120 °C |
| Nominal diameter connection 1 | DN 12 |
| Surface treatment connection 1 | Untreated |
| Surface protection connection 1 | Untreated |
| Key width | 24 mm |
| Swivel wrench size | 24 mm |
| External pipe diameter connection 1 | 15 mm |
| Complies with NF 545 | Yes |
