BONFIX brass compression fitting point piece 10 x 3/8 -40051125
€ 11,14
(Incl. 21%)
€ 9,21
(Excl. 21%)
- Brass nozzle
- Connection size: external thread 3/8 x 10 mm
- Assembly: with standard tools
- GASTEC/KIWA approved
- Suitable for gas, drinking water, and central heating installations
Loyalty Points
Earn from this purchase
+5
points
Max discount with points
5.57€
Using 558 points
Purchase this item to earn 5 points. As a loyalty member, you can use your points to save up to 5.57€ on this order!
Returns
14-day return policy
Secure Payment
Guarantee secure payments
24/7 Dedicated Support
Anywhere & anytime
Hotline Order:
Mon - Fri: 08:00 / 16:00
+31 854885920
Key features
- Brass nozzle
- Connection size: external thread 3/8 x 10 mm
- Assembly: with standard tools
- GASTEC/KIWA approved
- Suitable for gas, drinking water, and central heating installations
Product information
BONFIX compression fittings offer excellent value for money. The design of the fittings focuses on functionality and cost efficiency. This results in a flattened and sturdy wrenching surface for better grip during installation and a slightly conical locating surface in the union nut, allowing pipes to slide in easily and be securely connected.
Features
| Property | Value |
|---|---|
| Article number | 40051125 |
| GTIN number | 8717845211035 |
| Brand | BONFIX |
| Type | Point piece |
| Manufacturer's article number | 81103 |
| Mate | 10 x 3/8 |
| Model | Point piece |
| Application | Gas / Drinking water / CV |
| Tightening torque | 20 - 30 Nm |
| Connection 1 | Conical external thread BSPT-R (ISO 7-1 / EN 10226-1) |
| Connection 2 | Compression ring |
| Connection quality class 1 | CuZn40Pb2 (CW617N) |
| Connection quality class 2 | CuZn40Pb2 (CW617N) |
| Main color fitting | Brass |
| Material connection 1 | Brass |
| Material connection 2 | Brass |
| Material sealing | Brass |
| Max. operating pressure at max. medium temperature | 16 bar |
| Max. working pressure at 20°C | 16 bar |
| Medium temperature (continuous) | -20 - 120 °C |
| Model | 1-piece |
| Nominal diameter connection 1 | 3/8" (10) |
| Nominal diameter connection 2 | DN 8 |
| Surface treatment connection 1 | Untreated |
| Surface treatment connection 2 | Untreated |
| Surface protection connection 1 | Untreated |
| Surface protection connection 2 | Untreated |
| Swivel wrench size | 17 mm |
| External pipe diameter connection 1 | 16662 mm |
| External pipe diameter connection 2 | 10 mm |
| Form | Law |
