BONFIX brass compression fitting point piece 15 x 1/2 -40051245
- End piece transition from compression to thread
- Brass wear-resistant and suitable for long-term use
- 15 mm compression fitting for copper pipe
- 1/2 inch male thread for standard female thread connections
- Assembly without soldering or pressing tools
- Easy tightening with standard tools
- Approved KIWA and GASTEC QA compliant
Loyalty Points
Earn from this purchase
Max discount with points
Hotline Order:
Mon - Fri: 08:00 / 16:00
+31 854885920
Key features
- End piece transition from compression to thread
- Brass wear-resistant and suitable for long-term use
- 15 mm compression fitting for copper pipe
- 1/2 inch male thread for standard female thread connections
- Assembly without soldering or pressing tools
- Easy tightening with standard tools
- Approved KIWA and GASTEC QA compliant
Product information
The BONFIX brass compression fitting 15 x 1/2 is used to connect a 15 mm copper or central heating pipe to a component with a 1/2 inch internal thread. Examples include shut-off valves, taps, or other fittings in water, gas, or central heating systems. The compression side provides a secure seal on the pipe, while the external thread side allows for a traditional screw connection. Installation is quick and straightforward using standard tools, without soldering or crimping.
Why BONFIX?
BONFIX compression fittings combine practical use with reliable performance. Details such as the sturdy wrenching surface provide extra grip during tightening, while the union nut is designed to smoothly accommodate the pipe. The fitting is designed according to EN 1254-2, meets European UBA requirements, and is KIWA and GASTEC QA certified. This makes the end piece widely applicable in professional installations where a reliable connection is essential.
Features
| Property | Value |
|---|---|
| Article number | 40051245 |
| GTIN number | 8717845211202 |
| Brand | BONFIX |
| Type | Point piece |
| Manufacturer's article number | 82741 |
| Mate | 15 x 1/2 |
| Model | Point piece |
| Application | Gas / Drinking water / CV |
| Tightening torque | 28 - 50 Nm |
| Connection 1 | Conical external thread BSPT-R (ISO 7-1 / EN 10226-1) |
| Connection 2 | Compression ring |
| Connection quality class 1 | CuZn40Pb2 (CW617N) |
| Connection quality class 2 | CuZn40Pb2 (CW617N) |
| Main color fitting | Brass |
| Material connection 1 | Brass |
| Material connection 2 | Brass |
| Material sealing | Brass |
| Max. operating pressure at max. medium temperature | 16 bar |
| Max. working pressure at 20°C | 16 bar |
| Medium temperature (continuous) | -20 - 120 °C |
| Model | 1-piece |
| Nominal diameter connection 1 | 1/2" (15) |
| Nominal diameter connection 2 | DN 12 |
| Surface treatment connection 1 | Untreated |
| Surface treatment connection 2 | Untreated |
| Surface protection connection 1 | Untreated |
| Surface protection connection 2 | Untreated |
| Swivel wrench size | 24 mm |
| External pipe diameter connection 1 | 20955 mm |
| External pipe diameter connection 2 | 15 mm |
| Form | Law |
