BONFIX brass compression fitting point piece 15 x 3/8 - 40051145
€ 6,24
(Incl. 21%)
€ 5,16
(Excl. 21%)
- Brass nozzle
- Connection size: external thread 3/8 x 15 mm
- Assembly with standard tools
- GASTEC/KIWA approved
Loyalty Points
Earn from this purchase
+3
points
Max discount with points
3.12€
Using 313 points
Purchase this item to earn 3 points. As a loyalty member, you can use your points to save up to 3.12€ on this order!
Returns
14-day return policy
Secure Payment
Guarantee secure payments
24/7 Dedicated Support
Anywhere & anytime
Hotline Order:
Mon - Fri: 08:00 / 16:00
+31 854885920
Key features
- Brass nozzle
- Connection size: external thread 3/8 x 15 mm
- Assembly with standard tools
- GASTEC/KIWA approved
Product information
BONFIX compression fittings offer excellent value for money. The design of the fittings is based on functionality and cost reduction. This translates into a flattened and sturdy wrenching surface for better grip during installation and a slightly conical locating surface in the union nut, allowing pipes to slide in easily and be connected.
Product features
| Property | Specification |
|---|---|
| Article number | 40051145 |
| GTIN number | 8717845211103 |
| Brand | BONFIX |
| Type | Point piece |
| Manufacturer's article number | 82740 |
| Mate | 15 x 3/8 |
| Model | Point piece |
| Application | Gas, drinking water, CV |
| Tightening torque | 28–50 Nm |
| Connection 1 | Conical external thread BSPT-R (ISO 7-1 / EN 10226-1) |
| Connection 2 | Compression ring |
| DIN-CERTCO certificate | No |
| DVGW certification for gas | No |
| DVGW certification for water | No |
| Eccentric | No |
| FM approval | No |
| Gastec QA | No |
| Certified according to NF 545 | No |
| High tensile strength | No |
| Main color fitting | Brass |
| KIWA certification | No |
| KOMO certification | No |
| Connection quality class 1 | CuZn40Pb2 (CW617N) |
| Connection quality class 2 | CuZn40Pb2 (CW617N) |
| LPCB certification | No |
| Material connection 1 | Brass |
| Material connection 2 | Brass |
| Material sealing | Brass |
| Max. operating pressure at max. medium temperature | 16 bar |
| Max. working pressure at 20°C | 16 bar |
| Medium temperature (continuous) | -20 to 120 °C |
| With TUV approval | No |
| With connection indicator | No |
| With drain valve | No |
| With air vent | No |
| With gaskets | No |
| With bumper lug/edge | No |
| With thermal insulation | No |
| Model | 1-piece |
| Nominal diameter connection 1 | 3/8" (10) |
| Nominal diameter connection 2 | DN 12 |
| Surface treatment connection 1 | Untreated |
| Surface treatment connection 2 | Untreated |
| Surface protection connection 1 | Untreated |
| Surface protection connection 2 | Untreated |
| Swivel wrench size | 24 mm |
| System-related | No |
| Type approval according to BBR / EKS | No |
| UL mark | No |
| ULC approval | No |
| External pipe diameter connection 1 | 16.662 mm |
| External pipe diameter connection 2 | 15 mm |
| VdS approved | No |
| Running | No |
| Form | Straight |
